Chugger T-MAX Recirculation Pump

CAD $805.62

The Chugger T-MAX Recirculation Pump is a perfect pairing for recirculating filtered hash water back to the A-series agitation vessel. This 17GPM pump is targeted towards 25-65 gallon hash extraction systems and can move large amounts of water with ease. These pumps are designed to maximize flow rates while being relatively economical compared to standard commercial pumps.

Easy disassembly and a sanitary design guarantees your will not have unwanted microbes brewing in your pump.

The housing can handle liquids down to 0C /32F and features a 1.5″ Tri-Clamp center inlet, and a 1.5″ Tri-Clamp output. Having Tri-Clamp connections built directly into the brew pump allows for the full use of 1.5″ TC hardware (such as our sanitary hoses). When operating the pump, please note that the inlet should never be restricted, only the outlet.

Please Note: The pump head and lines need to be full before the pump is started. DO NOT RUN DRY



**back ordered with no updates on availability from the manufacturer**

Out of stock

Description

Specifications:

  • Max Flow: 17 GPM 64.4 LPM
  • Max Head: 27 FT 8.2 M
  • Power: .125 HP .093 KW
  • Electrical: 115V & 230V
  • Inlet: 1.5″ Tri-Clover
  • Outlet: 1.5″ Tri-Clover
  • Non-Submersible
  • 60HZ 50HZ
  • RPM: 3500
  • Fan Cooled Motor
  • Motor AMP Rating – Full Load Amps (FLA)
  • Motor Only: 1.4 Amps
  • Motor and Pump: 2.0 Amps
  • Can handle liquids of 32-250°F  (0-121°C)
  • Materials are FDA Food Compliant
  • Components are UL Recognized
  • DO NOT RUN DRY

Includes:

  • 316 Stainless Steel (Front Housing)
  • 316 Stainless Steel (Rear Housing)
  • PTFE (Thrust Washer)
  • CLEAR Silicone (O-Ring)
  • Ryton/PTFE (Impeller)
  • Custom Extra Long 10′ Power Cord
  • Chugger Max contains sealed bearings – no oil necessary
Hashtek at The Smoking Jacket

Don’t miss any blog posts!

Additional information

Weight 14 lbs
Dimensions 14 × 9 × 7 in
